Self-propelled Cold Solvent Road Marking Machine - -
Product details of the self-propelled cold solvent road marking machine
Quick Detail
Jiangsu Luxinda Traffic Facilities Co.,Ltd. always gives its customers surprises by offering new ideas and outstanding designs. Our unique products bring reliable performance to users. With good conveniences, the product is easy to apply in different scenarios.
Product Introduction
Next, Luxinda will present you with the specific details of self-propelled cold solvent road marking machine.
Related Parameters
|
Specification |
|
|
It is designed for large-scale road,especially apply to city road,airport and express way etc. It can mark actual line,dotted line,double yellow line etc. It is equipped with double spray gun and double paint bucket,also can add additional manual spray gun, to make it mark lines in different color at the same time. |
|
|
Maximum flow |
18L×2 |
|
Maximum work pressure |
30Mpa |
|
Spraying width |
50-900mm |
|
Spraying thickness |
0.2-0.6mm |
|
Work performance |
Four spray guns can work together |
|
Dimension |
1530×1230×1380mm |
|
Net weight |
820kg |
|
Main engine configuration |
Truck loading configuration |
|
270 Honda engine |
Automatic break line machine (SIMENS) |
|
Gear pump |
Manual controller (SIMENS) |
|
Oil tank |
Shelf of the spray gun (one group) |
|
Pressure regulator |
two solenoid valves (COMAZZI) |
|
Accumulator |
two automatic spray gun |
|
Reverser |
four pieces of high pressure tube(3.5m) |
|
Reversing oil tank |
Rotary encoder(OMRON) |
|
Paint high pressure pump |
10m High pressure tube,one manual spray gun |
|
Strainer |
One Yellow Paint bucket and one white Paint bucket |
|
Air compressor |
One set of Water line shelf |
Product Details
Application Scenario
Company Introduction
is an advanced and leading self-propelled cold solvent road marking machine supplier. Currently, we have quickly expanded our business operation range to the overseas self-propelled cold solvent road marking machine markets. Now, we provide services for customers in America, Europe, and Aisa. We understand sustainability as an affirmative action to minimize the negative impact on the environment. This is to be created in close dialogue and partnership with all of our stakeholders. For example, we promote fair and safe working conditions and green procurement in the supply chain.
Customers who need our products are welcomed to contact us for consultation.
