Road Line Marking Machine by-2
Product details of the road line marking machine
Quick Detail
road line marking machine is produced introducing the world-class technology and equipment. road line marking machine provides high reliability and superior performance at a low cost. Jiangsu Luxinda Traffic Facilities Co.,Ltd. is in strict accordance with the ISO9001 quality management system.
Product Information
More detailed information about road line marking machine will be shown below for you.
Related Parameters
|
Specification |
|
|
It is special equipment to normal temperature paint construction. It is suitable for roads, highway, parking lot,airport, station. It can mark a straight line, dotted line, curve, zebra crossing, arrows, etc. It is the spray equipment with high pressure,equal discharge and airless. It use gasoline engine to drive single plunger pump to work,which can generate high pressure inside the machine.The lines are common in thickness and angles are clear. Because of the direction bar in the spraying gun, the line can be adjusted to certain width conveniently. |
|
|
Engine |
5.5HP gasoline engine |
|
Work pressure |
10-18Mpa |
|
Max Flow |
6L/min |
|
Spraying width |
50-300mm(single gun) |
|
Spraying thickness |
0.2-0.6mm |
|
Size |
1180×860×1000mm |
|
Net weight |
145kg |
